Freewing Zeus 90MM 6S EDF Sport Jet Blue
Original price was: Rp11.600.000.Rp10.250.000Current price is: Rp10.250.000.
The latest addition to Freewing’s lineup of sport jets is the 90mm Zeus. Boasting a sleek and highly aerodynamic design, the Zeus 90mm is Freewing’s fastest sport jet to date. The 6S version of this jet can reach speeds of up to 150 miles per hour (240 km/h) in level flight.
In stock
Description
The latest addition to Freewing’s lineup of sport jets is the 90mm Zeus. Boasting a sleek and highly aerodynamic design, the Zeus 90mm is Freewing’s fastest sport jet to date. The 6S version of this jet can reach speeds of up to 150 miles per hour (240 km/h) in level flight. Its striking blue, grey, and white livery ensures it stands out boldly in the skies.Designed with impressive attention to detail, the wings of the Zeus are attached without the need for glue or screws, thanks to a quick-release wing lock mechanism, making wing installation and removal a quick and straightforward process.Each control surface is operated by a 17 gram metal gear servo, ensuring quality and reliability. Available in 6S and 8S configurations, the Zeus boasts the most powerful thrust-to-weight ratio among all Freewing sport jets before it. Soar into the skies and experience the exhilarating thrill and eye-catching speed of the Zeus!
Features
- Boasting speeds of up to 150mph (240km/h) in level flight, our newest 6S sport jet leads the fleet
- Engineered with a sleek aerodynamic profile, delivering unmatched performance in sport jet aviation
- Facilitated by a quick-release mechanism, the main wings offer hassle-free attachment and removal
- Enhanced grass-field operations are ensured by CNC-machined landing gear struts featuring a trailing link design
- For optimal visibility, daylight-bright LED lights adorn wing tips, fuselage, and nose gear strut
- Paired with a 12-blade, factory-balanced EDF, the jet is powered by either a 3668-1960Kv brushless inrunner motor, guaranteeing exceptional performance and sound
- Precise control is achieved with a 120 Amp ESC, complete with 8A UBEC and thrust reversing capability
- Control surfaces are managed with accuracy by seven 17g digital metal gear servos, while nose gear steering and doors are handled by two 9g digital hybrid metal gear servos
- Reduced drag and improved performance are facilitated by fully sequenced gear doors, including inner main gear doors
- Durability is enhanced with nylon hinges employed on all control surfaces
Technical Specifications
- Wingspan: 1200mm / 47.24in
- Length: 1450mm / 57.08″
- Take off weight: 2820g / 98.95oz (w/o battery)
- Motor: 6S 3668-1960Kv Brushless Inrunner Motor
- ESC: 120A thrust reversing, EC5 Connector
- EDF: 90mm 12-Blade EDF
- Servos: 17g Digital MG servo x7, 9g Digital Hybrid servo x2
- Landing gear: Electronic retractable landing gear with metal shock absorbing struts
- Battery: 6 Cell 22.2V 5000 mAh LiPo and 2 Cell 7.4V 5000 mAh LiPo batteries with EC5 connector in series or Two 4 Cell 14.8V 5000 mAh LiPo batteries with EC5 connector (required)
- Radio: 7 channels
- Rudder: Yes
- Flaps: Yes
- Ailerons: Yes
- Lights: Yes
- Hinge type: Nylon Reinforced
- Material: EPO Foam
- Recommended skill level: Intermediate
- Assembly time: 1 hour
- Recommended environment: Outdoor, 150+ foot paved runway or short manicured grass
Includes
- Freewing Zeus 90mm 6S Sport Jet PNP
- EDF, ESC, Motor, servos, LED, retracts included and installed
- Instruction manual
Requires
- 7+ Cell Channel Radio
- 7+ Cell Channel Receiver
- 6 Cell 22.2V 5000 mAh LiPo and 2 Cell 7.4V 5000 mAh LiPo batteries with EC5 connector in series or Two 4 Cell 14.8V 5000 mAh LiPo batteries with EC5 connector
- LiPo charger minimum 6S
Color scheme and appearance
Freewing Zeus is primarily colored in blue and white, and is painted with high contrast color blocks that stand out in the air. The fuselage section is relatively square, with a smaller overall cross-sectional area and reduced aerodynamic resistance. Horizontal tail lower reverse design can increase the elevator efficiency and increase the rudder stability.
LED lights and cabin doors
This jet includes 4 pcs navigation lights and 1 pcs front landing gear taxi light. Complete front/rear landing gear doors, it will close the doors during flight to minimize flight resistance.
Landing gear
Both the front and rear landing gears adopt a rocker arm structure, which has good shock absorption effect. The adhesive area of the front and rear landing gear fixed mounts is increased, the structure is optimized, the unloading force is dispersed, and the impact resistance is stronger.
The front and rear fuselage
The front and rear fuselage are assembled with buckle structure and screws to facilitate storage in the later period. This design reduced packaging volume significantly, saved shipping costs, and reduced the use of packaging materials, making it more environmentally friendly.
“Quick” II screw-less portable install structure of Main wing
For the main wing, one of the most frequently disassembled components, we designed the “Quick” II screw-less portable install structure. With gentle pressure, the main wing can be detached or installed. Convenient transportation and facilitate storage.
High strength main wing
The main wing made of 20x high-strength EPO material can withstand the huge load brought by a maximum speed of 300km/h. Note: 20 times high strength EPO material is only applicable to the main wing, excluding the other parts of the aircraft.
Other wings
Horizontal tail and vertical tail used the screws to fix without glue, convenient for transportation and facilitate storage.
Control surface
Continuing to use the Freewing Model traditional hidden control surface hinge, the structure is sturdy and the appearance is exquisite.
Control surface Arm
The upper and lower double layer plastic parts, double fixed with glue and screws, connected with metal ball heads, more smooth movement of the pushrod.
Equipment usage space
Large equipment usage compartment space can accommodate all 6S/8S batteries suitable for the 90 series EDF jet. After simple space expansion and modification, all necessary equipment suitable for turbojet flight can also be installed.
Thoughtful design of important logos
The lower surface of the main wing has a center of gravity marking line. Get the accurate important information anytime, anywhere.
Rich Power system options
6S PNP version: It pre-installed 3668 in-runner motor with 90-12 blade plastic ducted fan and 120A ESC with thrust reverse function.
Extensibility – Gyro
The “FreewingGuard” Six-Axis gyro effectively enhances the flight experience and escorts you! A new “Freewing Guard” gyro, after download the app, you can freely set the gyroscope parameters on your phone through the Freewing Blue Bridge. What you move with your fingertips is what you think! For more details on Freewing Guard, please click to know!
Extensibility – Tail after burner LED light
Motor tail prefabricated 2 screw holes, you can install the tail after burner LED light according to requirements.
Notes: Gyro dand Afterburner LED dibeli terpisah, tidak termasuk dalam paket PNP.
 |
Feel The Need For Speed?
The Freewing Zeus 90mm EDF is the fastest sport jet developed by Freewing to date. At 130mph straight-line speed out of the box (6S PNP), the Zeus is sure to quench your thirst for acceleration. |
 |
Quick-Install & Release Wings
The Zeus 90mm EDF features a screwless quick release wing design that makes field assembly and disassembly a breeze. |
 |
Slow Your Roll
The Zeus includes a thrust-reversing ESC (PNP versions) enabling a brake-like effect, effectively reducing your roll out on landings. This is especially useful on shorter, paved runways. |
 |
Grass Friendly
The Zeus 90mm EDF sport jet comes with CNC-machined struts with a trailing link design that can handle most reasonably-mowed grass fields with ease. |
 |
Navigation and Position Lights
The Zeus features daylight-bright LED lights on the wing tips, top and bottom of the fuselage, as well as a landing light that is mounted on the nose gear strut. |
 |
Vivid Color Scheme
The color scheme on the Zeus is bright and vivid, providing great visibility in all types of situations and conditions. |
 |
Great Sound and Power
The Zeus 90mm EDF 6S PNP sports the new 12-blade 90mm EDF unit with a powerful 3668-1960Kv inrunner motor for high end EDF jet performance. |
 |
Full Landing Gear Doors
The Zeus has fully sequenced gear doors, including inner main gear doors for lower drag and better sport jet performance. |
| Wingspan | 1200mm / 47.24in |
| Length | 1450mm /57.08in |
| Empty Weight | 2820g / 99.47oz (w/o battery) |
| CG (Center of Gravity) | 120mm (4.7″) from the leading edge of the wing at the root |
| Power System | 6S 3668-1960Kv Brushless Inrunner Motor |
| Electronic Speed Control | 120A thrust reversing, EC5 Connector |
| Propeller / EDF | 90mm 12-Blade EDF |
| Servos |
|
| Landing Gear | Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
| Required Battery | 6S 22.2V 5000mAh LiPo with EC5 connector (required) |
| Required Radio | 7 Channel (required) |
| Ailerons | Yes |
| Elevator | Yes |
| Rudder | Yes |
| Flaps | Yes |
| Lights | Yes |
| Hinge Type | Nylon Reinforced |
| Material | EPO Foam |
| Skill Level | Intermediate |
| Build Time | 1 Hour |
| Recommended Environment | Outdoor, 150+ foot paved runway or short manicured grass |
Additional information
| Weight | 18 kg |
|---|---|
| Dimensions | 117 × 35 × 30 cm |
| Batt. Capacity (mAH) | |
| Battery Cell (S) | |
| Color | |
| EDF (MM) | |
| ESC (A) | |
| Fuselage (MM) | |
| Wingspan (MM) | |
| Min. Channel | |
| Retractable? | |
| Completeness | |
| Volumetric | 20.48 kg |
